船舶中控室星空体育app在线 工控防水按鍵開關
詳細介紹
船舶中控室星空体育app在线,室外防水按鍵開關，航海設備專用防水按鍵開關，汽車手柄按鈕，室外適用星空体育app在线，工控防水按鍵開關 5A大電流防水按鍵開關，替代OTTO品牌按鍵開關，抗UV按鍵開關，光麵防水按鍵開關,室外專用防水按鍵開關
船舶中控室星空体育app在线,室外防水按鍵開關，航海設備專用防水按鍵開關，汽車手柄按鈕，室外適用星空体育app在线，工控防水按鍵開關 5A大電流防水按鍵開關，替代OTTO品牌按鍵開關，抗UV按鍵開關，光麵防水按鍵開關,室外專用防水按鍵開關
ELECTRICAL RATING:
Resistive: 28VDC 5A 4A(DB) 25,000cycles
Resistive: 115VAC 1A 1A(DB) 25,000cycles
Inductive: 28VDC 2A 2A(DB) 25,000cycles
Contact Resistance: 50mΩ Max.
Insulation Resistance: 1GΩ @ 500DVC
Dielectric Strength:AC 1000V 1 minute
Mechanical Life:1,000,000cycles
Operating Temperation:-40°C~+85°C
Switch action: Momentray
Switch circuitry: SPDT-DB ,load 1N.O./1N.C. 2 Circuit Life
Actuator Ingress Protection: IP67,IP68S,and IP69K (Front Panel).
Total traver: 1.6mm max.
Operating Force :1.7lbs [770g]. Release Force :12oz [340g]
Stands: UL61058 ROHS
