抗UV防水按鍵開關
詳細介紹
抗UV按鍵開關，光麵防水按鍵開關,室外專用防水按鍵開關
大電流小型防水按鍵開關，直流電星空体育app在线,低溫環境使用的按鈕開關，高壽命防水按鍵開關，汽車防水按鍵開關。
ELECTRICAL RATING:
ELECTRICAL RATING:
Resistive: 28VDC 5A 4A(DB) 25,000cycles
Resistive: 115VAC 1A 1A(DB) 25,000cycles
Inductive: 28VDC 2A 2A(DB) 25,000cycles
Contact Resistance: 50mΩ Max.
Insulation Resistance: 1GΩ @ 500DVC
Dielectric Strength:AC 1000V 1 minute
Mechanical Life:1,000,000cycles
Operating Temperation:-40°C~+85°C
Switch action: Momentray
Switch circuitry: SPDT-DB ,load 1N.O./1N.C. 2 Circuit Life
Actuator Ingress Protection: IP67,IP68S,and IP69K (Front Panel).
Total traver: 1.6mm max.
Operating Force :1.7lbs [770g]. Release Force :12oz [340g]
Stands: UL61058 ROHS
