水下機器人防水金屬按鍵開關

所屬分類：16mm金屬按鈕開關
點擊次數：
發布日期：2023/07/09
更多
在線詢價

詳細介紹

產品名稱：IP68防水金屬開關
直徑：16mm
產品簡介：IP68防塵 防水按鍵開關，防水按鍵開關不鏽鋼，金屬防水按鍵開關防水防塵效果高達IP68，
自鎖式或複位式，內部防水達到IP68且內建三色LED切換功能。適用於需要防水，沙塵，和其他汙染物的環境，應用於野外車輛，農用器械，機械工具，加工工具和醫療器械
認證：歐規/美規認證齊全。安全認證：TUV/CQC....
16mm Waterproof Pushbutton Switches
SPECIFICATIONS
SAFETY/QUALITY APPROVALS
TUV/CQC/CE/SGS/REACH/IP68/CTUVUS
Panel Thickness: Ø16.20/19.20mm
Contact Rating: lth 5A/250VAC resistive load 3A/250VAC
Mechanical Life: Momentary 200,000 cycles Self-lock 100,000 cycles
Electrical Life: 50,000 make-and-break cycles at full load
Torque: 5~14Nm
Travel: About 3.0mm
Operation Pressure: 2.5±1N
Contact Resistance: 50 mΩ max.
Insulation Resistance: 100MΩ min.
Dielectric Strength: 2,000 Vrms @sea level.
Operating Temperature: -20°C to 85°C
Ingress Protection: IP68
MATERIALS
BUSHING : Stainless Steel / Nickel plated brass / Aluminum alloy
BASE : PBT, PA66
ACTUATOR : Sillicone .
INNER ASSEMBLY : POM / PA66.
SPRING : Spring steel.
SEALING : Sillicone.
O-Ring : Sillicone
TERMINAL : Brass,with silver or gold plated.
HEX NUT : Nickel plated brass
Led: 1.8V/3V/6V/12V/24V/36V/48V/110V/220V
ILLUMINATION BASE RATlNG：
Red， Yellow and Orange：20mA 1.8V;
Blue, Green and White：20mA 2.8V
Beads Color：R/U/G/Y/0/W
