IP68帶燈線上星空体育网址大全
所屬分類:IP68防水線上開關
- 點擊次數:
- 發布日期:2024/12/06
- 在線詢價
三色燈線上開關(guan) ,IP68防塵防水按鍵開關(guan) ,防水線上開關(guan) 線上星空体育网址大全,防水線上開關(guan) ,防水帶線按鍵開關(guan)
Waterproof Pushbutton Switches
SAFETY/QUALITY APPROVALS
SGS/REACH/IP68
SPECIFICATIONS
Contact Rating: 50mA 12VDC
Mechanical Life: Momentary 100,000 cycles Self-lock 50,000 cycles
Electrical Life: 50,000 cycles make-and-break cycles.
Travel: About 2.0mm
Operation Pressure: About 8N
Contact Resistance: 50 mΩ max.
Insulation Resistance: 100MΩ min.
Dielectric Strength: 500 Vrms @sea level.
Operating Temperature: -20°C to 85°C
Ingress Protection: IP68
RoHS
MATERIALS
Bushing : PA66
Base : PBT/PA66
Actuator : PA66
Inner Assembly: POM / Sillicone.
Spring : Spring steel.
Sealing: Sillicone.
O-Ring : Sillicone
Led: 1.8V/3V/6V/12V/24V/36V/48V/110V/220V
ILLUMINATION BASE RATlNG:
Red, Yellow and Orange:20mA 1.8V;
Blue, Green and White:20mA 2.8V
Beads Color:R/U/G/Y/0/W
產(chan) 品應用:便攜式工具和機床、測驗設備、售貨機及飲水設備、戶外防水設備
燒烤爐及商用廚房設備、公共交通控製、白色家電、通信設備、醫療設備、電動車行業(ye)
計算機機箱、安防及門禁係統、警報設備和安全係統、數據錄入設備、自動化設備、儀(yi) 器儀(yi) 表
汽車軌道交通、酒店設備、照明燈具、電動玩具、電網電力係統、美容器材、音響視頻設備、機器人
食品加工設備、運輸起重裝置、辦公設備、3D打印設備
