多檔位鑰匙開關選型資料
詳細介紹
19mm鑰匙開關 4A鑰匙開關，DC電壓鑰匙開關
Introduction
No. S2031
Product Name S2031
Description
Zinc alloy die cast housing and cylinder.
Bright chrome plated standard.
Double-bitted brass keys
11 disc tumbler mechanism.
Double-bitted brass keys
Key may be withdrawn in one or two positions.
Spring loaded for momentary contact.
Golden plated contacts and terminals.
Hex nut or speed clip mounted.
All keyed alike or 5 combinations standard.
5 combinations available.
SPECIFICATION
Contact Rating: 4A 125VAC, 2A 250VAC.
4A 28VDC
Contact Resistance: 50Milli-Ohms Max.
Insulation Resistance: 500 Meg-Ohms Min.
(500VDC)
Dielectric Strength: 1000 VAC -1 Minute.
