多種鑰匙組合電源鎖
詳細介紹
19mm鑰匙開關，4A鑰匙開關，大電流鑰匙開關，多種鑰匙組合形式鑰匙開關
產品型號：S246-3C
產品名稱：KEYLOCK SWITCH
產品說明：
鋅合金鎖殼，鎖心，三價鋅電鍍
鎖殼包白鐵蓋，附防塵塊
5個排片
雙邊銑齒銅鑰匙，鍍鎳
鑰匙可單抽或者雙抽
鍍銀接點及端子
3支端子，通電方式OFF-ON
鎖頭固定方式為六角螺母
規格品為同號或25組鑰匙組合
最多有100組鑰匙組合
Introduction
No. S246-3C
Product Name S246-3C
Description
Zinc alloy die cast housing and cylinder.
Bright chrome plated standard.
Stainless steel capped bezel, dust shutter mechanism.
5 disc tumbler mechanism.
Reversible double-bitted brass keys, nickel plated.
Silver plated contacts and terminals.
2 position off-on， 3 terminals.
Hex nut mounted.
SPECIFICATION
Contact Rating: 4A 125VAC, 2A 250VAC
Contact Resistance: 10 Milli-Ohms Max.
Insulation Resistance: 500 Meg-Ohms Min. (500VDC)
Dielectric Strength: 1000 VAC - 1 Minute.
19mm鑰匙開關，4A鑰匙開關，大電流鑰匙開關，多種鑰匙組合形式鑰匙開關
產品型號：S246-3C
產品名稱：KEYLOCK SWITCH
產品說明：
鋅合金鎖殼，鎖心，三價鋅電鍍
鎖殼包白鐵蓋，附防塵塊
5個排片
雙邊銑齒銅鑰匙，鍍鎳
鑰匙可單抽或者雙抽
鍍銀接點及端子
3支端子，通電方式OFF-ON
鎖頭固定方式為六角螺母
規格品為同號或25組鑰匙組合
最多有100組鑰匙組合
Introduction
No. S246-3C
Product Name S246-3C
Description
Zinc alloy die cast housing and cylinder.
Bright chrome plated standard.
Stainless steel capped bezel, dust shutter mechanism.
5 disc tumbler mechanism.
Reversible double-bitted brass keys, nickel plated.
Silver plated contacts and terminals.
2 position off-on， 3 terminals.
Hex nut mounted.
SPECIFICATION
Contact Rating: 4A 125VAC, 2A 250VAC
Contact Resistance: 10 Milli-Ohms Max.
Insulation Resistance: 500 Meg-Ohms Min. (500VDC)
Dielectric Strength: 1000 VAC - 1 Minute.
